Fan coil units
MAJOR 300
A I R C O N D I T I O N I N G - R E F R I G E R A T I O N - A I R H A N D L I N G - H E A T E X C H A N G E -
N
N
A
A
0
0
4
4
.
.
5
5
0
0
2
2
B
B
T
ECHNICAL
CHARACTERISTICS
Motor technical characteristics 230V- 1ph-50Hz
MAJOR 300
Motor ref.
325
327
327 SP
329
329 SP
331
333
Power input
(w)
R1
59
63
102
105
139
R2
52
54
85
89
125
R3
44
46
77
79
111
R4
38
39
69
72
98
R5
35
35
57
56
91
R6
31
31
48
48
83
R7
28
27
41
41
75
Absorbed intensity
(A)
R1
0,25
0,27
0,44
0,46
0,59
R2
0,22
0,23
0,37
0,39
0,53
R3
0,19
0,19
0,33
0,34
0,48
R4
0,16
0,17
0,30
0,31
0,42
R5
0,15
0,15
0,25
0,24
0,39
R6
0,14
0,14
0,21
0,21
0,36
R7
0,13
0,13
0,18
0,18
0,33
Coil contents (liters)
MAJOR 300
325
327
327 SP
329
329 SP
331
333
2-pipe system
Heating and
cooling coil
0.4
0.57
0.7
0.78
0.96
1.8
2.2
4-pipe system
Cooling coil
0.51
0.72
0.9
1
1.2
2.3
2.8
Heating coil
0.13
0.17
0.2
0.23
0.29
0.49
0.6
MAJOR 300
325
327
327 SP
329
329 SP
331
333
2-pipe system
Heating and
cooling coil
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 1/2"
G 1/2"
4-pipe system
Cooling coil
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 1/2"
G 1/2"
Heating coil
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
MAJOR 300
325
327
327 SP
329
329 SP
331
333
2-pipe system
Heating and
cooling coil
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 1/2"
G 1/2"
4-pipe system
Cooling coil
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 1/2"
G 1/2"
Heating coil
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
G 3/8"
MAJOR 300
325
327
327 SP
329
329 SP
331
333
2-pipe system
Heating and
cooling coil
G 1/2"
G 1/2"
G 1/2"
G 1/2"
G 1/2"
G 3/4"
G 3/4"
4-pipe system
Cooling coil
G 1/2"
G 1/2"
G 1/2"
G 1/2"
G 1/2"
G 3/4"
G 3/4"
Heating coil
G 1/2"
G 1/2"
G 1/2"
G 1/2"
G 1/2"
G 1/2"
G 1/2"
Coil outlets diameters (female tapped connector)
2-way vave outlet diameters (female tapped connector)
2-way and 4 way valves outlets diameters (male tapped connector)
Be careful :
in case of the 2-way valve, connectors ar not always identical.Y
ou must use different boards.
Ex :
NCH329 - 2-pipe equipment with 2-way valve :
V20A :Female tapped coil wire 3/8" fitting and 3/8" female tapped valve
V2000
®
:
Female tapped coil wire 3/8" fitting and 1/2" male threaded valve
