Fan coil units
MAJOR 300
A I R C O N D I T I O N I N G - R E F R I G E R A T I O N - A I R H A N D L I N G - H E A T E X C H A N G E -
N
N
A
A
0
0
4
4
.
.
5
5
0
0
2
2
B
B
NCV
MODEL
DIMENSONS
Mounting 1 V
wall - mounting - total indoor air intake
Mounting 2 V
with legs - total indoor air intake
Mounting 5 V - 6 V
indoor and outdoor air intake with by-pass flap
Mounting 7 V - 8 V
total outdoor air intake
61
550
630 mini
Section hole = B x 140
Attachment = D
Section hole = C x 110 (Front)
Mounting 1V
Mounting 2V
Mounting 5V
Mounting 6V
Mounting 7V
Mounting 8V
Section hole = C x 110 (Front)
Section hole = E x 90
(base or rear)
Accessories (supplied separately)
h
Aluminium grille and telescopic connector (optional)
k
Support base
l
Indoor / outdoor air intake box
m
Indoor / outdoor air intake box equipped with a damper control servo-motor
n
T
otal outdoor air intake box with removable panel 1 for filter withdrawal
o
Diffusion grille in aluminium (optional)
MAJOR
A
B
C
D
E
F
325
910
875
450
500
430
720
327 - 327 SP
1060
1025
600
650
580
870
329 - 329 SP
1260
1225
800
850
780
1070
331
1460
1425
1000
1050
980
1270
333
1660
1625
1200
1250
1180
1470
