5
Fan coil units
MAJOR 300
A I R C O N D I T I O N I N G - R E F R I G E R A T I O N - A I R H A N D L I N G - H E A T E X C H A N G E -
N
N
A
A
0
0
4
4
.
.
5
5
0
0
2
2
B
B
MAJOR
A
B
C
Unit mass in kg
1
2
5 - 6
7 - 8
325
825
500
430
26
28
32
30
327 - 327 SP
975
650
580
29
31
36
33
329 - 329 SP
1175
850
780
36
38
44
41
331
1375
1050
980
42
44
51
47
333
1575
1250
1180
49
51
60
55
D
IMENSIONS
OF
CV
MODEL
-
WALL
MOUNTING
Mounting 1 - 2
total indoor air intake
Mounting 5 - 6
indoor and outdoor air intake with by-pass flap
Mounting 7 - 8
total outdoor air intake
Coil pipe access flap
Aluminium diffusion outlet
Control unit access flap
Mounting 1
Mounting 2
Mounting 5
Mounting 6
Mounting 7
Mounting 8
Section hole = C x 90
(Base or rear)
Accessories (supplied separately)
a
Support feet
d
d Indoor / outdoor air intake box with recovery grill 1 for filter withdrawal
e
Indoor / outdoor air intake box with recovery grille fitted with a damper control servo-motor
g
Total outdoor air intake box with removable panel 2 for filter removal
h
Aluminium grille and telescopic connector (optional) The layout 2 can be equipped with and alumium indoor
air intake grille identical to mounting 5 and 6 (accessory b).
