Fan coil units
MAJOR 2
A I R C O N D I T I O N I N G - R E F R I G E R A T I O N - A I R H A N D L I N G - H E A T E X C H A N G E -
N
N
A
A
0
0
4
4
.
.
5
5
0
0
1
1
B
B
T
ECHNICAL
CHARACTERISTICS
Pipe diameter at outlets (trapped fittings)
The diameters of the female tapped fittings on coil connections pipes are standardised as below (see dimension drawing T)
MAJOR 2
426
428
430
432
434
435
2- pipe sytem
Heating or cooling
coil
3/8 "
3/8 "
3/8 "
3/8 "
1/2"
1/2 "
4- pipe sytem
Cooling coil
3/8 "
3/8 "
3/8 "
3/8 "
1/2 "
1/2 "
Heating coil
3/8 "
3/8 "
3/8 "
3/8 "
3/8 "
3/8 "
Diameters of valve outlets (threaded connections)
The diameters of the valves male threaded connections are standardised as above (see dimension drawing T2)
For units fitted with customer control valves, an intermediate two-part male/female connector is needed between the coil
connector and the valve(s).
This connector is available as an accessory (1, 2 or 4 connectors are required depending on the
configuration (2 or 4-pipe) and the valve type (2-way or 4-way) - consult us).
When a CIA
T valve-based control system is used, the two-part connector is integrated in the control loop.
Heater / cooler capacity (in litres)
MAJOR 2
426
428
430
432
434
435
2- pipe sytem
Heating or cooling
coil
0,53
0,76
0,99
1,32
1,58
1,58
4- pipe sytem
Cooling coil
0,53
0,76
0,99
1,32
1,58
1,58
Heating coil
0,13
0,13
0,25
0,20
0,24
0,24
Motor electrical characteristics (230/1/50)
MAJOR 2
Motor
ref.
426
428
430
432*
434
435
Absorbed power
(W)
R1
76
105
112
115
161
166
R2
64
89
92
95
140
143
R3
54
74
78
76
123
123
R4
45
62
64
63
106
106
R5
41
57
57
57
97
96
R6
37
51
50
50
88
85
R7
33
45
47
45
79
76
Absorbed Current
(A)
R1
0,33
0,44
0,48
0,49
0,67
0,72
R2
0,28
0,37
0,4
0,4
0,58
0,62
R3
0,24
0,31
0,34
0,33
0,52
0,54
R4
0,2
0,27
0,28
0,28
0,45
0,47
R5
0,18
0,25
0,25
0,26
0,4
0,43
R6
0,16
0,23
0,23
0,23
0,37
0,38
R7
0,15
0,21
0,22
0,21
0,34
0,34
MAJOR 2
426
428
430
432
434
435
2- pipe sytem
Heating or cooling
coil
1/2 "
1/2 "
1/2 "
1/2 "
3/4"
3/4"
4- pipe sytem
Cooling coil
1/2 "
1/2 "
1/2 "
1/2 "
3/4"
3/4"
Heating coil
1/2 "
1/2 "
1/2 "
1/2 "
1/2 "
1/2 "
Standard unit
T2
Unit with valve
(optional)
* Size 432SP characteristics are idendical of those of size 435
